Mixers
MACOM's mixers are offered as single, double balanced, and image reject covering narrow and wideband frequencies up to 64 GHz. Mixers are used in both up and down frequency conversion applications. These discrete passive mixers are offered in bare die, surface mount package, and connectorized form factors.
| Part Number | Description |
|---|---|
| MA4EX600L1-1225T | Double Balanced |
| MAMXSS0013 | Low Cost MMIC |
| MAMX-011021 | High IP3 Mixer, 5 - 33 GHz |
| MA4EX950H1-1225T | Double Balanced |
| CGY2183UH | Active Double Balanced Mixer |
| MAMX-000900-1061LT | HMIC Si Double Balanced |
| MAMX-009239-001500 | E-Series Surface Mount Mixer |
| MA4EXP240L-1277T | Silicon Double Balanced HMIC Mixer 2300 - 2800 MHz |
| MD-156 | Flatpack Double-Balanced Mixer |
| MAMX-011040-DIE | Image-Reject Mixer 8 - 26 GHz |
| MAMX-011040 | Image Reject Mixer, 8 to 26 GHz |
| MAMX-011035 | Double-Balanced Mixer 5.5 to 19 GHz |
| MAMX-011088-DIE | Double-Balanced Mixer 17 - 64 GHz |
| XM1003-BD | Image Reject Mixer |
| MAMX-011054 | Double-Balanced Mixer, 18 to 46 Ghz |
| MA4EXP950H1-1277T | High IP3 Double Balanced |
| MA4EX950L1-1225T | Double Balanced |
| MAMX-011044 | Image Reject Mixer 2.5 to 9 GHz |
| MAMX-011037-DIE | Double-Balanced Mixer, 18 – 46 GHz |
| CGY2184UH | Active Double Balanced Mixer |
| MAMX-011043-DIE | Image-Reject Mixer, 15 to 45 GHz |
| MAMX-011038 | Double-Balanced Mixer, 6 to 26 GHz |
| MAMX-009722-25MHLP | E Series |
| MAMX-011009 | Sub-Harmonic Pumped Mixer |
| MAMX-011036 | Double-Balanced Mixer, 8 to 43 GHz |
| MAMX-008611 | Low Cost MMIC |
| MAMX-090950-1277LT | High IP3 Double Balanced |
| MAMX-011071 | Double-Balanced Mixer 8 - 36 GHz |
| MA4EX240L1-1225T | Double Balanced |
| MAMX-011144 | Double-Balanced Mixer |
| MAMX-011116 | Image-Reject Mixer 32 - 37 GHz |
| MAMX-011074 | Double-Balanced Mixer 18 - 46 GHz |
| XM1002-BD | Image Reject Mixer |
| MAMX-011036-DIE | Double-Balanced Mixer, 8 to 43 GHz |
| MAMX-011097 | 2 mm Image-Reject Mixer 32 - 37 GHz |
| CGY2182UH | Double Balanced Mixer |
| CGY2181UH | Double Balanced Mixer |
| MAMX-011122 | Double-balanced Mixer 17 - 53 GHz |
| MAMX-011067 | Double-Balanced Mixer 5 - 20 GHz |
| MA4EX580L1-1225T | Silicon Double Balanced HMIC |
| MAMX-011034 | Double-Balanced Mixer, 3 to 12 GHz |
| MAMX-011075 | Image Reject Mixer 8 - 26 GHz |
| MAMX-011023 | Low Noise Active Mixer, 4 – 23 GHz |
| CGY2180UH | Double Balanced Mixer |
| XM1001-BD | Image Reject Mixer |
| MAMX-011044-DIE | Image Reject Mixer 2.5 to 9 GHz |
| MAMX-011066 | High Linearity Mixer 5 - 37 GHz |
| MAMX-011126 | Double-Balanced Mixer |
| MAMXSS0012 | Low Cost MMIC |
| MAMX-011043 | Image-Reject Mixer, 15 to 45 GHz |
| MAMX-011088 | Double-Balanced Mixer 17 - 55 GHz |
